Recommendation on RF Cluster Connector – Antenna to Radio Module Pinout Alignment
This White Paper adresses the alignment of 8T8R antenna and 8T8R radio module pinout with a unique naming system and pinout order on repeatable basis to simplify rigging of installations. This shall help to mimimise the potential for cross feeder/connection issues.
The goal is to have one simple naming convention which allows different vendors to manufacture only one product variant to simplify deployment logistics and future site maintenance.
This document is the output of Phase 2 of the NGMN cluster connector project.
